39 Years of card_1 in the field
The following projects have been planned with card_1.
You'd like to publicize an exciting project of yours? We can work together to prepare your project descriptions, reports or photos, which we will then publish online and in our customer magazine interAktiv. Contact us on email to the interAktiv editorial department.
-
Noise Barriers for card_1
Model creation is becoming increasingly important in early planning phases as it accelerates decision-making processes. It makes all the more sense to use CardScript to check whether data from other software solutions can be used to “quickly” build specialist models.
-
CardScript for BIM Track Modelling
The BIM method is becoming increasingly important, yet challenges remain. 3D models with attributes are needed to work meaningfully with BIM without any loss of information. Manual procedures make updating arduous and difficult to manage. Integrated solutions must therefore be found that automate processes and work steps in order to manage large volumes of data. What could be more obvious than CardScript?
-
Roadway and Bridge planned with BIM
Calculating complex intersections and checking the clearance of the road under a railway line - these were the challenges for BIT Ingenieure AG in a 2019 traffic route project. The card_1 Bridge Generator was used then the data was evaluated and checked via DESITE BIM.
-
Renewal of Kirchhain Railway Station
Kirchhain station is in the central regional area of DB Station&Service AG and is managed by Gießen station management. Mailänder Consult GmbH used the card_1 module Platform Generator to plan the outer and middle platforms.
-
A 111 Rehabilitation
The company Deutsche Einheit Fernstraßenplanungs- und -bau GmbH DEGES commissioned the Schüßler-Plan/VIC consortium with planning the rehabilitation of the A 111 motorway using BIM as the mandatory planning method.
-
5D BIM in municipal road building
With an innovative project in the field of road construction, students at Biberach University of Applied Sciences have won the Virtual Academy A6's BIM 2021 Award. The ten-member project team used the software solutions card_1, DESITE BIM and customX to develop their results.
-
East Africa‘s Gateway to the World
The state-owned port operator Kenya Ports Authority is investing in the future. The port of Mombasa is being further expanded as a central hub in East Africa. Since 2014, Inros Lackner has been supporting the development of the port with general planning services ranging from the creation of a master plan to technical and special planning through to construction supervision. Johannes Augustin
-
Once around Lake Alster by bike
The Free and Hanseatic City of Hamburg is gradually putting its safe cycling concept into effect. There are already 14 cycling routes, so-called Veloroutes, interconnecting the city’s districts. Now, over the course of several construction phases, the traffic routing around the Außenalster (Outer Lake Alster) is being adapted to make it more bike-friendly. BPR Künne & Partner is undertaking this redesign for the Harvestehuder Weg to Bellevue section.
-
BIM in Road Planning
In a BMVI pilot project directed by DEGES, the preliminary planning phase of a 14.0km long section of the B87 between Eilenburg and Mockrehna is being examined using BIM. The engineering company Schüßler-Plan is contributing directly to the testing and development of the BIM method in this pilot project. IB&T is supporting Schüßler-Plan as a development partner.
-
Traffic Planning on Borkum
The design of a shopping street, a 3D visualisation and a rigorous analysis of 3D modelling - these are the most important aspects dealt with using card_1 in Stefanie Katthose's bachelor's dissertation.
-
B 178n - Planning with BIM
In the south-east of Saxony, the B 178n is being built as a high-throughput connection between the A4 motorway near Weißenberg and the 3-country triangle (D/PL/CZ) in near Zittau. In Section 1.1, the federal highway is to have a three-lane cross-section over a length of 5.3km. The engineering office EIBS completed the draft planning for the traffic systems using the BIM method.
-
An Unparalleled Construction Project
Not only is it the largest earthworks project in Bickhardt Bau AG‘s 45-year history, right now it‘s also Europe‘s most extensive.
-
Been on your bike today?
Could rapid bike paths be the transit ways of the future? Klinger und Partner GmbH of Stuttgart (KuP) show how unused thoroughfares can be converted and re-deployed in a more contemporary fashion. Covering a wide area with rapid transit bike paths is one way to link key locations over large distances. Such paths would have to be safe, attractive and designed for high-speeds.
-
Digital into the Future
The engineering office Jermann Ingenieure + Geometer AG was given the job to survey around 14 kilometres of track for the railway company Baselland Transport AG (BLT). Here follows a discussion with the project leader Michael Schrattner and head of the surveying team Pascale Spychiger about the challenges in railway surveying, working at night and friendly tram drivers.
-
Mega Project in Ivory Coast
Following years of bitter political crisis, Côte d‘Ivoire is now working to re-establish its political stability and economic pre-eminence in West Africa. Infrastructure in particular is to be upgraded in order to foster neighbouring and international trade. One such measure is to extend the existing A3 highway inland by 132km. The entire new section of road into the centre of the country was designed using card_1.
-
Theological and Secular Influences
The city of Paderborn's central and much loved cathedral and market square is getting a facelift. The remodelling will both reflect the city's rich history as well as providing all those who use the square with an attractive space to spend their time. And right at the forefront are BPR of Hanover with card_1 of Norderstedt.
-
Rail Planning in Hungary
The InfraPlan Eisenbahn- und Straßenplanung AG has been using the surveying and design software card_1 since 2003 and in that time has designed many major stretches of Hungarian railway. They are currently working on upgrading the Szajol-Püspökladány train line, a large-scale project due for completion in October 2015.
-
Planning the M-4 in Russia
The Russian M-4 is a highway connecting the capital of Moscow to the Black Sea coast via Voronezh and Rostov-on-Don. Parts of this major north-south connection are to be revamped and some sections upgraded to a motorway. This is a pilot project in which Russian and German infrastructure planners are working together on one section of the designs, following German guidelines and Russian principles.
-
Point Clouds – not Steam Clouds
On the 25 October 2013 a RailMapper completed its surveying tasks along the Windbergbahn track – a first on German railways. This two-mode vehicle (HiRail) enabled quick, precise recording of the existing conditions thanks to its built-in terrestrial laser scanning technology. The data was evaluated using card_1.
-
Hamburg Lid in Sight
Today's planning processes demand a clear communication of the final designs to the public – especially when highly complex structures are involved, such as expanding the capacity and covering the A7 motorway in Hamburg. INTER OFFICE GmbH of Dresden has taken up the challenge: they have visualized and simulated plans for the Hamburg Stellingen section of motorway based on the data provided by card_1.
-
All Systems Go in Brandenburg
The Havelland motorway junction joins the A10 and A24 federal motorways and plays an important role in the national motorway network. Unfortunately it's plagued by congestion and tail-backs. Solving this problem will not only improve traffic flow but should also foster the regional economy. The company VIC Verkehrsanlagen GmbH has been tasked with designing the enlargement of the junction – a juicy challenge for surveyors, planners and card_1.
-
Good and fast – mobile laser scanning on the A7 motorway
The PRO-Survey Ingenieurbüro für Vermessung was awarded the contract to log and evaluate the existing conditions of a 67km stretch of the A7 motorway between the junctions Hamburg Nordwest and Bordesholm. They were only given four weeks for the job. Their solution to this demanding task? Mobile laser scanning in combination with the surveying and design software card_1.
-
A7 Roadworks – A Noise-Lid on Hamburg
Three tunnels are to provide a lid on the noise of the A7 motorway. Engineering office BUNG Ingenieure AG of Dresden have used card_1 to plan the widening of part of the complex Stellingen section of motorway between junctions Hamburg(HH)-Nordwest and HH-Volkspark.
-
Abu Dhabi on Track
The Department of Transport (DoT) has now given the design phase of the Abu Dhabi rail project the green light. The first construction phase will involve a two-track network for the Metro, two tram lines and an express bus route. The DoT is using the current card_1 Version 8.4 to check the line routing.
-
Designed at Formula 1 Speed
Twelve months to build a new, state-of-the-art Formula 1 circuit – can’t be done? Yes, of course it can! - Thanks to the company Bickhardt Bau AG from Kirchheim, Germany, which built the new Formula 1 Mecca in Abu Dhabi. They are specialists in building racing tracks and transportation routes and were awarded the contract to build all subbase and asphalt layers of the racetrack as well as the peripheral area.
-
Drainage using the XSection Designer - Extension of the A8
The six lane extension of the A81 presented planners with a special challenge, especially when it came to drainage. The A81 is an important European north-south connection. It completely crosses the state of Baden-Württemberg and connects the cities of Würzburg, Heilbronn and Stuttgart with the area around Lake Constance.
-
Warsaw North Bridge
In June 2007, the engineering company Schüßler-Plan was put in charge of planning the North Bridge "Trasa Mostu Pólnocnego". It was to be completed within 282 days.
-
Mutlangen's North and West Bypass Roads
The opening of the north and west bypass roads has significantly reduced Mutlangen's through-traffic, thus removing a tailback-creating bottleneck. Mutlangen lies at the junction of three regional connecting roads: the B298 from Schwäbisch Hall, the L1155 from Welzheim-Alfdorf and the L1156 from Ruppertshofen-Lindach.
-
Drainage Planning for Winden
The engineering office F&L GmbH planned the entire drainage facilities for the municipality of Winden in the Elztal region of Baden-Württemberg. The municipality contracted F&L to provide an overall approvable design of the future waste water and surface drainage facilities, taking state-of-the-art hydrologic and hydraulic computer-based calculation methods into account, as new building land was to be created and the bypass B 294 was to be extended.
-
The way is cleared for amphibians
In the district of Traunstein a complex amphibian guidance system has been integrated into the planned walking and bicycle track project alongside an important road between Bergen and Staudach. The construction serves to improve traffic conditions and protect the local ecological system.
-
Complete redevelopment of inner-city streets in Dakar
In the year 2000 the Agence d'Execution des Travaux d'Interet Public contre le Sous-emploi commissioned a local engineering office with the complete redevelopment of certain inner-city streets in the capital city of Dakar. This agency is a public body in Senegal whose mandate is to initiate job-creating projects.
-
Kerala State Highway
A total of 1000km of the Kerala State Highways were revised using card_1 so that the road network could fulfil growing demands. Kerala (Malayalam) is an Indian state and lies on the Malabar coast in south-west India. It is one of the most densely populated regions of the country.
-
A roundabout in Prien
The market town of Prien is an air-therapy spa, the only Kneipp spa in Upper Bavaria and the largest community on Lake Chiemsee. The rise in traffic volume and heavy transport unable to quickly reach the motorway resulted in the redevelopment of a crossing and the new development of a roundabout in the town centre.
-
Metro Amsterdam - De Noord / Zuidlijn
The Dutch metropolis of Amsterdam is extending its metro network with a north to south connection. The 9.5 km route from Buikslotermeerplein via Centraal Station to Zuid/WTC is designed to extend the existing network and to relieve the above ground traffic systems.
-
Dubai gets a new local train
The construction industry is booming in Dubai like nowhere else in the Arabian world. One of these huge projects involves building a new local railway network. When planning, the Dubai RTA-Rail Agency engineers place their trust in card_1. The basic concept behind the Dubai Metro envisages building two railway lines which should be partially operational by mid-2009.
-
World-class Traffic System
Abu Dhabi, the capital of the United Arab Emirates, is investing heavily in traffic infrastructure projects with a view to becoming a metropolis with an environmentally friendly and sustainable world-class traffic system.
-
Digital Project Approval Procedure in Karlsruhe
The Karlsruher Schieneninfrastruktur-Gesellschaft mbh (KASIG/Rail Infrastructure Company in Karlsruhe) plans to build a local railway tunnel and to redesign a street with an above-ground tram line route in Karlsruhe's inner city. Turning this so-called combination solution into reality is the leading town planning project for the city of Karlsruhe. For the first time, the company KASIG used the digital presentation solution card_1 eView for the project approval procedure.
-
Kinshasa - Redesign of the Route National No. 1
One of the most important tasks in civil war-stricken Congo is extending the traffic route network. As part of the redesign of the RN1 from Kinshasa to Matadi, Gauff Ingenieure GmbH was awarded the contract to plan and to prepare the project tender.
-
Reconstruction of the Station Überlingen
The new train station Überlingen/Town Centre was designed to improve the link between the public transport system's road and rail networks. The station is located within the area of the existing tunnel mouth on both sides of the street Wiestorstraße along the train route Stahringen-Friedrichshafen.
-
New tram link: from Halle to HaNeu
Building an east-west tram line which connected the suburb of Halle-Neustadt to the city centre as well as to the existing tram network was the ambitious public works project of the city of Halle/S. Project work began in 1996 and accompanied construction work until 2003.
-
DB AutoZug Sylt Shuttle in Niebüll
The Sylt Shuttle facilities in Niebüll have been completely modernised to produce an advanced, customer-friendly product called DB Autozug Sylt Shuttle. ICB Hamburg GmbH was awarded the contract to plan the re-development of the existing transport facilities (road/rail) and to modernise the existing level crossing.
-
3D Project View in Traffic Systems Construction
The roundabout in Kirchhorst, Lower Saxony, was planned with the aid of 3D visualization in order to give the local council an additional decision-making tool.
-
Channelling Traffic in Stuttgart
Although Stuttgart 21 is currently the city's hottest topic, Stuttgart also has other large-scale projects in the pipeline. One of which is planning the Rosenstein tunnel, another is re-engineering the B10/B14 junction at Leuze. Both projects aim at drawing traffic away from Stuttgart's residential side streets, currently used as shortcut thoroughfares, and back onto the B10 highway. Hyder Consulting GmbH Deutschland was tasked with planning these projects.
-
Re-routing the B36
Because of the high traffic load and the situation within the town it became necessary to relieve the municipalities Durmersheim and Bietigheim by building a bypass.
-
Linking the Rostock Tram Network
By order of the Rostocker Straßenbahn AG and the DB Station & Service AG Hamburg the Rostock tram lines were linked to the rail network of the German Federal Railways. Train travellers are now able to get to the city centre quickly and easily as can residents of south Rostock.
-
Building the 4th Elbe Tunnel Tube
The acronym TRUDE means, in German, "Tief runter unter die Elbe" (deep down under the Elbe). Trude is the biggest shield-tunnelling machine worldwide with a diameter of 14.20 m. It drilled its way under the Elbe from south to north with a soil cover of between 7 and 13 m.
-
Yongwu – Heading up into the Interior
It will play a vital role in the development of the infrastructure and the economy of this rough mountainous region. The design institute used card_1 for this challenging project.
